CIJ CONTINUOUS INKET PRINTERS

EC-JET1100

The EC-JET1100 is a compact, efficient, and affordable CIJ printer that includes many features usually only found on more expensive models. The easy-to-use colour touch screen monitor provides quick and user-friendly code inputs and changes, allowing for fast changes between product runs. Its compact size makes it easy to move between line locations. And its stainless-steel body with sealed printhead ensure a long useful product life in challenging production environments.

PRODUCT FEATURES

High Value Features

  • Durable stainless-steel cabinet
  • Sealed printhead for reduced maintenance
  • Easy-to-use colour touch screen display
  • Durable ruby nozzle for long life reliability
  • RFID to prevent accidental use of incorrect ink or solvent
  • Reverse printing function

Special Functions

  • Easily adjustable print height, width, and position
  • Graphics and message input via USB flash drive
  • Backup, restore, and software update by USB flash drive
  • Simple character/message bolding function
  • Optional remote communication interface
  • Customizable shift codes

Other Features

  • Unique three-door design for easy maintenance access
  • Compact cabinet for fitting in tight spaces and easy relocation
  • Efficient design for reduced fluid consumption
  • Advanced Viscosity Control System to ensure print clarity and stability

Print Sample

PRINTING SPEED AND SIZES
Lines of Print
1-5 Lines
Message Height
Up to 32 dots (20mm)
Maximum Line Speed
Up to 240m/min
HARDWARE FEATURES
Screen Size / Message Entry
8.0 inches – Colour Touchscreen
Ink Supply
RFID
Preventive Service Interval
6 Months
Service Interval Method
Printhead Shut Down Method
Auto Stop Selection
Pumping System
Gear Type
Software Features
On-Screen Help and Diagnostics
Live Message Preview
Step-By-Step Guidance
Message and Settings Back-Up
Barcode Printing
Option
Printhead Features
Nozzle Size
60µm or 50µm
Umbillical Conduit Length
2.0m or 3.0m
90 Degree Printhead Available
-
Ink Range
Dye-based
Pigmented
-
Connection Interface
Product Detector
Alarm Output
Shaft Encoder
Input Connector
USB
Ethernet
Optional
